RIGOL DHO1072 디지털 오실로스코프 (70 MHz; 2+EXT)

Specifications

Analog Bandwidth (-3 dB) : 70 MHz

Input Channels: 2+EXT

Rise Time (10% to 90%,Typical): ≤5 ns

Sampling Mode: Real-time sampling

Max. Sample Rate of Analog Channels:

+  2-channel model: 2 GSa/s (single channel[1]), 1 GSa/s (all channels[3])

+  4-channel model: 2 GSa/s (single channel[1]), 1 GSa/s (half channels[2]), 500 MSa/s (all channels[3])

Standard Memory Depth

+  2-channel model: 50 Mpts (single channel[1]), 25 Mpts (all channels[3])

+  4-channel model: 50 Mpts (single channel[1]), 25 Mpts (half channels[2]), 12.5 Mpts (all channels[3])

Optional Memory Depth

+  2-channel model: 100 Mpts (single channel[1]), 50 Mpts (all channels[3])

+  4-channel model: 100 Mpts (single channel[1]), 50 Mpts (half channels[2]), 25 Mpts (all channels[3])

Max. Waveform Capture Rate

+   50,000 wfms/s (Vector Mode)

+   1,500,000 wfms/s (UltraAcquire Mode)

Vertical Resolution: 12 bits

Hardware Realtime Waveform Recording and Playing: Up to 500,000 frames

Peak Detect: Capture glitches as narrow as 2 ns

Display Size and Type:  10.1-inch capacitive multi-touch display

Display Resolution:  1280 × 800

Power

Power Voltage: AC 100 to 240 V, 50 to 60 Hz

Power: 400 VA maximum (connect various interfaces, USB storage device, and active

probes)

Fuse: 3.15 A, T degree, 250 V

Environment

Temperature Range: Operating: 0℃ to +50℃; Non-operating: -30℃ to +60℃

Humidity Range:

+ Operating:

      below +30℃, ≤90% RH (without condensation)

      +30℃ to +40℃, ≤75% RH (without condensation)

      +40℃ to +50℃, ≤45% RH (without condensation)

+ Non-operating below 60℃: ≤90% RH (without condensation)

Altitude:

+ Operating Below 3,000 m

+ Non-operating Below 15,000

Mechanical Characteristics

Dimensions: 358.14 mm (W) x 214.72 mm (H) x 120.62 mm (D)

Rack Mount Kit: 4U

Weight[6] Net: 3.8 kg; Shipping: 5.37 kg

Non-volatile Memory

Data/File Storage:

+ Setup/Image: setup (*.stp), image (*.png, *.bmp, *.jpg)

+ Waveform Data: CSV waveform data (*.csv), binary waveform data (*.bin,), list data (*.csv), and reference waveform data (*.ref, *.csv, *.bin)

Internal Capacity: 8 GB

Reference Waveform: Displays 10 internal waveforms

Setting: Limited by size of USB drive

USB Capacity: Industry standard flash drives
